Nytro 10XN EVO Super Grade Transformer Oil

NYTRO 10XN EVO meets and exceeds IEC 60296:2020 edition 5.0, and is a Type A fully inhibited oil, classified as TVAI. Outstanding features for Nytro 10XN EVO includes superior oxidation stability for a longer transformer life, and excellent low temperature properties.

Product benefits

• Viscosity at -30°C max 800 cSt
• Viscosity at -35°C max 1800 cSt
• LCSET -35°C
• Pour point max -51°C

Features

• Extremely good heat transfer. Due to its low viscosity and viscosity index, this transformer oil offers extremely good thermal properties, ensuring efficient heat transfer from the transformer core and windings.

• Excellent low temperature properties. Naphthenic characteristics allow the transformer to start at the lowest possible temperature – without using pour point depressants.

• High dielectric strength. This insulating oil both meets and exceeds the toughest demands on dielectric strength - when stored and handled correctly.

• Outstanding oxidation stability. Developed and formulated to deliver maximum resistance to oil degradation, this grade provides outstanding oxidation stability for enhanced transformer life and minimum maintenance.
